M3IE Force/torque indicator, 220V Europe
Price: $ 504.00
2,000 Hz sampling rate
0.2% accuracy
USB output
Price:$525.00
Advanced 3i Force / Torque Indicator |
The 3i digital force / torque indicator is designed to work with a wide range of Mark-10 remote force and torque sensors (see page 3). With exclusive Plug & Test technology, all calibration and configuration data is saved within the sensors smart connector, not the indicator, allowing for true interchangeability. In addition, all sensors are fully compatible with the advanced 5i force / torque indicator.
The 3i shares its menu structure and most specifications with Series 3 digital force gauges. The sampling rate is 2,000 Hz, producing accurate results under a wide range of test conditions. A backlit graphic LCD displays large characters, and a menu is available to access the gauges features and configurable parameters. The display also features an analog load bar for graphical representation of applied load, as well as set point indicators for pass-fail testing. USB output is provided for data collection purposes. The gauges include MESURTM Lite data acquisition software. MESURTM Lite tabulates continuous or single point data. One-click export to Excel allows for further data manipulation. |
 Features of the Series-3I Advanced Force/Toruqe Indicator
 Interchangeable force and torque sensors through Plug & Testtechnology | | Peak readings and set points always displayed | | External trigger mode - for switch contact testing or remotely stopping display update | | USB data output | | Configurable audio alarms and key tones | | Configurable audio alarms and key tones | | MESURTM Lite data collection software included |
| | High-speed 2,000 Hz sampling rate | | Ultra-compact size | | Programmable set points with pass/fail indicators | | Live load bar graph with set point markers | | Programmable auto-shutoff | | Battery or AC operation | | CE mark |
|
Photo Gallery for the Series-3I Advanced Force/Toruqe Indicator - click any photo to enlarge
| Unique Plug & TestTM technology allows for interchangeable sensors to be used with a Mark-10 model 5i or 3i indicator. All calibration and configuration data is saved in the smart connector. |
Dimensions of the Series-3I Advanced Force/Toruqe Indicator
Complete Kit of the Series-3I Advanced Force/Toruqe Indicator
The 3i indicator includes a carrying case, universal voltage AC adapter, battery, quick-start guide, USB cable, resource CD (USB driver, MESUR Lite software, MESURgauge DEMO software, and user's guide), and NIST-traceable certificate of calibration. |  |
Download of the Series-3I Advanced Force/Toruqe Indicator
Specifications of the Series-3I Advanced Force/Toruqe Indicator
| Accuracy | 0.2% of full scale 1 digit + sensor | | Sampling rate | 2,000 Hz | | Power | AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low. | | Battery Life | Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use | | USB Output | By pressing DATA key only. Configurable up to 115,200 baud. | | Configurable Settings | Digital filters, USB output settings, backlight, automatic shutoff, key tones, audio alarms, default settings, calibration | | Safe overload | 150% of full scale (display shows OVER at 110% and above) | | Weight | Weight: 0.7 lbs (0.3 kg) | | Included items | Carrying case, universal voltage AC adapter, battery, quick-start guide, USB cable, resource CD (USB driver, MESURTM Lite software, MESURTMgauge DEMO software, and user's guide), NIST-traceable certificate of calibration. | | Warranty | 3 years (see individual statement for further details) |
